Introduction
Lost a bolt, nut, or washer which connects the fender to your eBike? Take a look at this chart to see what size it is! With this size, you can go to a local hardware store and get a replacement right away!
Not sure which fork you have? Check some of the example images (coming soon)!
Fork Name | Part | Screw Size |
RST Guide | ||
Fork Arch Mount | M6x40 w/ M6 Nylock Nut and 2x M6 Washers | |
Fender Stay | M5x15/20 x2 | |
RST Renegade | ||
Fork Arch Mount | M6x15 | |
Fender Stay | M5x12/15 x2 | |
Suntour NEX | ||
Fork Arch Mount | M6x40 w/ M6 Nylock Nut and 2 M6 Washers | |
Fender Stay | M5x12/15 x2 | |
Zoom Fork (Swift Lite) | ||
Fork Arch Mount | M6x20 | |
Fender Stay | M5x12/15 x2 | |
Mozo Fork | ||
Fork Arch Mount | M6x40 w/ M6 Nylock Nut and 2x M6 Washers | |
Fender Stay | M5x15 x2 | |
Biktrix Inverted (KKE/GTMAK) | ||
Fork Arch Mount | M6x15 | |
Fork Arch Mount | M6x30 | |
Fork Arch Mount | M6 Washers | |
Rockshox Recon | ||
Fork Arch Mount | M6x12/15 | |
Rockshox 35 | ||
Fork Arch Mount | M6x15 | |
Fender Stay | M5x10 |
